ISM43439-WBP-L151

The ISM43439-WBP-L151The ISM43439-WBP-L151 SiP (System In Package), is an “ALL” Infineon based IoT platform (Infineon Radio + Infineon MCU + Certified Antenna). The ISM43439-WBP-L151 SiP is also a cost-effective, high performance and secured IoT architecture with one of the industry’s only dedicated Wi-Fi 4 solutions to deliver the latest WPA3 security standard. As a Wi-Fi/Bluetooth/BLE combo chip for IoT applications, the new Inventek ISM43439- WBP-L151 module will make it easier for product designers to comply with new security regulations currently emerging worldwide, including the California Consumer Privacy Act. This, for example, gives more privacy rights to consumers, including the right to know about the personal information a business collects, and the right for that information to be deleted.
The Inventek ISM43439-WBP-L151 module also includes an integrated PSoC 6 MCU. Herald as the sixth generation of the PSoC family, PSoC 6 is purpose-built to speed the development of any IoT application, the ultra-low-power dual-core PSoC 6 family features both an Arm Cortex-M4 and Cortex-M0+ core. Ideally suited for battery-powered applications, the dual-core architecture permits embedded developers to optimize their design for power and performance. As with any IoT application, security is a primary requirement, and the integrated PSoC 6 MCU incorporates Arm’s latest platform security architecture (PSA).

Product Specifications

The Inventek ISM43439-WBP-L151 2.4G, 802.11 b/g/n serial-to-Wi-Fi + BT/BLE 5.2 + PSoC 6 MCU, module includes an integrated TCP/IP stack, an ARM Cortex-M4 + ARM Cortex-M0 (50MHz / 100MHz), 1MB of MCU Flash, 2MB QSPI Flash and 256KB of SRAM. The platform also supports a skew option for 1MB of MCU Flash, 2MB QSPI Flash and 1MB of SRAM. Options for both a fully certified internal chip antenna or U.FL external antenna are also supported.

Product Overview

  • Wi-Fi standards, speeds and security:
    • Single-band 2.4 GHz b/g/n with speeds up to 150Mbps
    • WEP, WPA/WPA3-R3
  • Bluetooth 3.0, Bluetooth 5.2 compliance (Bluetooth Low Energy
  • System-in-Package design, no need for external crystal oscillators or RF switches
  • Single supply voltage of 3.3VDC ±5%
  • 151 pin LGA package (10 mm x 10 mm, 1.2 mm)
  • FCC/CE/Wi-Fi certified based on Inventek reference design
  • Single Antenna support
